Ingress Protection*

External Active Antenna IP67

* The external active antenna can work normally in all-weather environments. The main unit of the P-9 Race is not waterproof.

Operating Temperature

-20°C to 50°C / -4°F to 122°F

GNSS Performance

GPS (L1C/A, 1575.42MHz), Galileo (E1-B/C, 1575.42MHz), GLONASS (L1OF, 1602MHz), BeiDou (B1I, 1561.098MHz), QZSS (L1C/A, 1575.42MHz), SBAS (EGNOS, GAGAN, MSAS, WAAS, QZSS L1S)

Positioning Ability*


Reacquisition : <2s
Hot start: <2s
Cold start: <29s
Horizontal position accuracy: better than 0.7m/CEP(50%), 2.0m/CEP(95%)
Vertical position accuracy: ±15m

* Support "EPS Race" technology. 25Hz mode. Data from testing in ideal open environments.

Output Sentences

Protocol: NMEA 0183
Messages: GNRMC, GNGGA, GNGSV, GNGSA (Default)
Geodesics: WGS84

Update Rate

25Hz (Deafult)

Bluetooth

SPP 2.1
BLE 5.1
Range: >10m (33feet)

Connectors

USB device: USB 2.0 Type-A
Active Antenna connectors: SMA
Antenna feeder: 300cm / 9.8feet

Power

P-9 Race: DC 5V / 70mA
External active antenna: DC 3.3V / 35mA

System Requirements

Windows 7 or greater
Mac OS X v10.10 or greater
Linux 2.6.12 or greater
iOS 15 or greater
Android 10 or greater
iPad OS 15 or greater
